Projects By Pinnacle Ductwork

Take a look at some of our projects!

With over 30 years of experience in sheet metal fabrication, we have completed so many different customer projects from residential all the way to commercial and industrial.

Our projects are completely bespoke and custom to you and your sketches - If you can draw it, we can make it!


Bespoke Ducting & Ancillaries

Design & Fabrication

Portable Centres offer a range of compact and easy to set up repair centres including body repairs, glass, tyres and MOT’s for high footfall areas such as supermarkets, retail parks and airports for same day automotive repairs.

We worked with Portable centres to design the ducting systems required for the range of portable centres, each with varying requirements depending on the levels of air handling/ventilation required.

We fabricated all of the ducting and ancillary items such as filter housing and shelving across the range of different portable centre designs.

 Bespoke Ducting & Ancillaries


Residential Duct For High Airflow Systems

Large Batch Production

We supplied metal 300 x 100mm ductwork for 800 dwellings at a new build development in Acton London where MVHR Heat Recovery system were being installed.

Due to overheating, higher airflow rates needed to be achieved, however ceiling voids were restricted. The 300 x 100mm ducting (not available in plastic) was the perfect solution to meet performance and installation requirements.

 Residential Duct For High Airflow Systems


Bespoke Acoustic Enclosure

Design & Fabrication

For this project, we were asked to design and maufacture an acoustic casing/surround for an external generator/plant room that was in close proximity to working offices We designed the casing in parts which was simply put together onsite.

 Bespoke Acoustic Enclosure


Designer Water Feature

Bespoke Metal Fabrication

For this client we were commissioned to create a stainless teel surround for a designer water feature at a private home in London.

We worked with the client to design a simple and aestheitcally pleasing surround housing which could be easily assembled onsite – a gorgeous finished product!

 Designer Water Feature


Commercial Ducting Replacement

HVAC Ducting

A simple sheet metal HVAC duct job in Southampton for a system installed in a commerical building. Standard rectangular ductwork with mez with a jet cowl termination.

 Commercial Ducting Replacement


New Amazon Warehouse

Manufacture & Supply

We manufactured and supplied sheet metal ducwork for the new HVAC system at a brand new Amazon warehouse located just a stones throw from our Havant based wokshop.

 New Amazon Warehouse
